Lissajous Figure By CRO study wave shapes trainer with CRO + audio Oscillator AE-1298K
When two signals of nearly equal frequency are applied to the X and Y plates respectively, the resultant wave form (Lissajous figure) will be an ellipse. In a similar way hysteresis loop of two signals can be traced
Apparatus :
(i) CRO 10 MHz
(ii) Audio Oscillator 10-Hz to 100 KHz
